RAM-GDS-CHARGE-PPS-CIGC RAM GDS® Type-C and Type A 2-Port Cigarette Charger
RAM-GDS-CHARGE-PPS-CIGC RAM GDS® Type-C and Type A 2-Port Cigarette Charger
MUST BE UNOPENED AND UNUSED TO QUALIFY FOR RETURN
FEATURES
- Two-port GDS® USB Type-C and USB Type-A cigarette charger; total output of 48W max
- USB Type-C port utilizes full 30W power delivery; built-in safeguards protect against over-current
- Supports PPS and PD3.0
- Backed by a 3-year warranty
This two-port GDS® USB Type-C and USB Type-A cigarette charger (RAM-GDS-CHARGE-PPS-CIGC) allows for charging two devices simultaneously. The USB Type-A port takes advantage of Qualcomm® Quick Charge™ 3.0 for compatible devices. With the USB Type-C port, utilize full 30W power delivery. To prevent overcharging and overheating, multiple built-in safeguards protect against over-current. The updated low-profile design now fits more flush in the vehicle’s charging socket, along with support of PPS and PD3.0 for better support for iPads and dynamic PD support.
PACKAGING TYPE
Retail Box
INPUT VOLTAGE
12V - 24V DC
POWER OUTPUT
48W Total (30W for Type-C & 18W for Type-A)
OUTPUT CURRENT
3A max
OPERATING TEMPERATURE
-10°C to +50°C
STORAGE TEMPERATURE
-20°C to +70°C
PORTS
(1) Type-C Female (PD)
(1) Type-A Female (QC 3.0)
COMPLIANCE
Short Circuit Protection, Over Voltage Protection, Over Current Protection & Over Temperature Protection
CERTIFICATIONS
FCC, Industry Canada, CE, RoHS, WEEE
WARRANTY
3 year warranty
WEIGHT
0.12 lb
